Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 107

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 107 — SECTION OF B MODEL LOOM CUT-MOTION WITHFULL TEN-INCH ROLL OF CLOTH. This cut is interesting in comparison with our later motion,which lias mam additional advantages. The fliter or reed-holder shown is not now used. io4 … ORIGINAL HIGH ROLL CUT-MOTION FOR E MODEL LOOM. The cut illustrates our earliest pattern of High Roll cut-motion. It was quickly superseded by the next type shown. io5

Looms · Weaving
