Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 55

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 55 — at a loose heel will not bringextra strain on the cutter and cause the temple to be reciprocatedthrough the cutter. It may be noticed that Filling-Changing mechanism includesfive distinct and separate devices, namely; the Filling-Changeritself, the Shuttle, the Shuttle Position Detector, the… … 53 As shown, the transferrer is placing the bobbin in theshuttle, the dog being in engagement with the hunter on the lay.The empty bobbin is falling down the chute into the box. The chute as first designed was a movable part, independent of thelay itself. This cut was made from our first model loom…
