Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)
Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 58
CROSS-SECTION OF A NO. 1 COP-HOPPER WITHTRANSFER TAKING PLACE. The entering cop skewer has just started the pressure thatexpels the one in the shuttle. It has still to move some distancedown the chute to reach the box. The expelled skewer is notempty in this instance, as it illustrates a case in… … DETAIL OF CONNECTION Between the filling fork which detects the absence of fillingand a No. i cop hopper or magazine. 56
Looms · Weaving
