Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 301

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 301
sur-rounding the tire are set up by hand screwsand a wrench, compressing the tire tightlyupon the wheel. 296 MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 77S. HYDRAULIC TLRE-SETTIXG MACHINE. A number ofcylinders and pistons set within a strong iron ring compress the tire upon the wheel by thepower… … 77Q. AUTOMATIC FURNACE for hardening and tempering balls.The balls are picked up by the small shelf in the revolving hop-per, and tipped into the mouth-piece, and carried along by thecentral screw ; transferred intothe outer and hotter reversescrew carrier to the chute, anddropped into a water…
