Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 99

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 99 — BARTLETT LET-OFF. The Bartletl was our standard until the Draper-Roper let-off appeared. We owned the original Snell and Bartlett patentand sold over 50.000 of them for use on old and new loomsbefore 1870. 96 … DRAPER-ROPER LET-OFF AND ANTI-BANG. The cut shows this let-off applied to a J model loom.Note the follower which hears against the warp on the heam.The operative parts are largely hidden from view. Note in the cut of the let-off another new idea which wecall the anti-bang. The fro- slide connects…

Looms · Weaving
