Dressings and finishings for textile fabrics and their application; description of all the materials used in dressing textiles (1911)

Polleyn, Friedrich, Salter, Charles · London, Scott, Greenwood · leaf 250

An illustration from Dressings and finishings for textile fabrics and their application; description of all the materials used in dressing textiles, 1911, leaf 250 — the squeezing rollers, F and G,where the superfluous starch is forced out. The fabric then passes,either over the guide roller, b, on the arm, U, and to the folder,X, Y, where it is laid in folds; or, when it is not to be folded, iswound up on a beam, M, which is pressed firmly against the… … Fig. 45.—Padding machine. (Gewebe=fabric. which the lower one, G, dips into the starch, and transfers thelatter to the back of the goods in revolving. The lower squeezing roller, G, is hollow, the walls being 1 inchthick, whilst the upper roller, F, is solid, to press the fabric. As arule, both…

Textile finishing

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
