Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 58

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 58
Early form of Thread-Cutting Temple. © … 1 - vl ■^ F.AJ- 1 PATD MAY28 IS95 n 4}\iS^^^ Later form of Thread-Cutting Temple. Made with soHd heel so that a loose heel will not bringextra strain on the eutter and cause the temple to be reciprocatedthrough the cutter. It may be noticed that Filling-Changing mechanism includesfive distinct and…

Looms

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
