hat a loose heel will not bringextra strain on the eutter and cause the temple to be reciprocatedthrough the cutter. It may be noticed that Filling-Changing mechanism includesfive distinct and separate devices, namely; the Filling-Changeritself, the Shuttle, the Shuttle Position Detector, the… … 53 As shown, tlie transferrer is placing the bobbin in theshuttle, the dog being in engagement with the hunter on the lay.The empty bobbin is falling down the chute into the box. Thechute as first designed ^^■as a mo\ al)le part, independent of thelay itself. This cut was made from our hrst model…
