Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 62

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 62
CROSS-SECTION OF A NO. 1 COP-HOPPER WITHTRANSFER TAKING PLACE. The entering cop skewer has just started the pressure thatexpels the one in the shuttle. It has still to move some distancedown the chute to reach the box. The expelled skewer is notempty in this instance, as it illustrates a case in… … DETAIL (3F COXXECTION Between the filling fork which detects the absence of filling and a No. i cop hopper or magazine. 5^

Looms
