Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 78

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 78
AU^vIAXX FEELER JUST BEFORE OPERATION. This cut shows tlie form of feeler mechanism devised byMr. Louis A. Ainiiann, a<i:ent of the Dwis^ht Mfof. Co. at Chic-opee and modified by inventions of \V. F. and C. FL Draper. … AUMANN FEELER OPERATING. We have had these applied to thousands of looms. They areindependent of the wear or alteration in the throw of the layand therefore require practically no adjustment after the firstsettino-. 72 eye to the cloth, while the bobbin itself is in the receptacle,thus leaving an…

Looms

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
