Leaf springs, their characteristics and methods of specification; a hand-book of useful information relating to automobile leaf springs, their manufacture, methods of specification, details and characteristics (1912)
Landau, David, ed, Sheldon axel Company · Wilkes-Barre, Pa., Sheldon axle company, Spring engineering department · leaf 27
Section at A B Fig. l: ing in a narrow slot or saw in the leaf above, see Figure 13.Metal i- removed from one leaf and metal distorted in the otherwhen securing the leaves in this way. It can, therefore, hardlybe recommended as the best practice. … Ribbing P—Special clip with tube H—Clinch clip G—Ribbed spring Fig. 14 Another means of securing the leaves in alinement is torib them, see Figure 14. The rib is supposedby many to extend the whole length of each leaf, andthey do in some foreign makes of springs. In reality it is madeStrength (),1b…
Automobiles
