Leaf springs, their characteristics and methods of specification; a hand-book of useful information relating to automobile leaf springs, their manufacture, methods of specification, details and characteristics (1912)
Landau, David, ed, Sheldon axel Company · Wilkes-Barre, Pa., Sheldon axle company, Spring engineering department · leaf 53
ing efficiency.We give below the actual figures as recorded in getting the springloads from a recent car. Total Weights Total weight with five passengers 4,300 pounds Total weight front end 1,795 Weight under left front wheel 875 A Typical \yeight under right front wheel (by Case in i( Detail… … STEEL STOCK NUMBKR ONK MlI,I, This contains stock for this mill only and is but a fraction of the entire stock carried Unsprung Weights Weight of the front axle 71 Weight of front wheels, tires, springs, etc 176 Total dead weight front end —71 + 176 2V* Weight of rear axle 321 Weight of rear…
Automobiles
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
