the beamswings over the scale, which iscalibrated to read in amperes. Aplumb-bob indicates when theinstrument is properly leveled.The instrument depicted illus-trates a 0 to 300 scale, and can becalibrated for a larger capacity,say 0 to 400 amperes, by slidingthe counterweight along the beam toward… … Fig. 191.—Balance Beam Gravity-Ammeter—Westinghouse Type. AMMETERS. 20b
