Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1903)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 382
in the arma-ture coils will notbe along the verticalline A B, Fig. 350,but along a linesomewhat in ad-vance of it, in thedirection of the ar-mature rotation, asthe line CD whichpasses through bothneutral points inthe field and isknown as the neu-tral line, or plane.Commutation of an armature coil… … 350.—Neutral Points Produced by theArmature Reaction. 364 PRACTICAL ELECTRICITY. line. The angle of advance of the neutral line from th«vertical position will depend upon the current flowing fromthe armature (the field distortion increasing with the current)being shifted forward for an increase,…
Electricity · Magnetism
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
