sure the potential dif-ference between a trolley line and the track which is about 550volts, and only a 150 volt instrument is available. Connect five 110-volt lamps in seriesand to the track and line, andparallel the voltmeter Mdtheach lamp respectively. Thesum of the voltages acrosseach lamp… … 30 VOLTS Fig. 215.—Measuring the VoltsDrop with a Voltmeter, resistances of 2, 3, 4, and 6 ohms respectively, are connected in ser-ies and to a battery. The spools may represent lamps, magnets, or MEASUREMENT OF PRESSURE. 241 6 VOLTS DROP
