rgecurrent. 237. Measuring High Voltages with a Low Range In-strument.—Suppose it is desired to measure the potential dif-ference between a trolley line and the track which is about 550volts, and only a 150 volt instrument is available. Connect five 110-volt lamps in seriesand to the track and… … 30 VOLTS 238. Measurements witha Voltmeter.— Exp. 65: Four spools of wireA, B, C, and D, Fig. 215, withresistances of 2, 3, 4, and 6 ohms respectively, are connected in ser-ies and to a battery. The spools may represent lamps, magnets, or Fig. 215-Drop -Measuring the Volts with a Voltmeter.…
