Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1902)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 276
Fig. 230.—Principle of the Wheat-stone Bridge. … 231.—Principle of the Wheat-stone Bridge. The resistance in the arm, A, bears the same relation to thatin B as the resistance in the rheostat at C does to the un-knowm resistance at D. Spools are selected for A and Band the resistance of C varied till the galvanometer needlestands at zero. A…
