Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1902)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 376
Fij. 336.—Laminated Armature Core. The thickness of the discs is maguified to show theeddy curreuts. ARMATURES. 357 … Fig. 337.—Corumutator forDirect Current Dynamoor Motor. and formed collar made of sheet mica, when it is ready forthe reception of the bais which are forged with grooves inthe ends, as in Fig. 339. The projecting insulated tongue onthe hub fits into a correspondinggroove in a bar, and when all…
Electricity · Magnetism
