Fig. 303.—Bipolar Dynamo or Motor. DYNAMO ELECTRIC MACHINES. 335 0f SAP … Fig. 304.—Dissected Bipolar Dynamo. LIST OF PARTS. F-Frame. A-Armature. C-Comrautator. C-Field coil complete. P-Part. B-Brush. W-Screws. FRAME-F. Part. Base, F 1 Field magnet, F 2 Pillow blk., lower part, F 3 Pillow blk., lower part couiui. end, F 3^ Pillow blk.,cap, F 4 Rocker arm, F 5 Binding…
