are in parallel with the brushes. As each coil passesfrom under the influence of the N-pole and comes intoaction under the S-pole, commutation takes place and thedirection of currentthrough it is reversed,as will be seen fromtracing the directionof the currents in thetwo upper coils, whichare… … Fig. 324.—Eight-Coil Gramme Ring- DirectCurrent Armature. short-circuit each coil for an instant as it passes from pole topole, and this short-circuiting should occur when there iszero E. M. F. in the coil, or at that instant when the mag-netic lines threading through it are a maximum, which will…
