348 PRACTICAL ELECTRICITY. … FigT* |26-—Battery Analogy of Induced E.M.F. in a Ring Armature. of this half of the ring, since these four coils are in series will therefore be 2 + 4 + 4 + 2 or 12 volts, and shS similar induction takes place in the other half of the ring at he same instant, there will be a total of 12 volts…
