rection of cur-rent underneath the needleas above it, the deflection is opposite to what it previously was. Xowbend the wire around the needle, at rest, parallel to it, so that the cur-rent flows over the needle and under the needle in opposite directions.The deflection is now in the same… … Fig. 74.—Simple Detector Galvanometer. 56 PRACTICAL ELECTRICITY.
