Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 31
FlG- 9- Fig. 10. Figs. 9 and 10.—Long rivets taken from a broken casting which they were intendedto secure to the wrought-iron head of the boiler. The holes in the wrought-iron platewere drifted and chipped to allow the rivets to enter, as shown by the enlarged portionof the body. This irregular…
Locomotives · Steam-boiler explosions
