Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 363
ear, andone on the second course, for the attachment of the safety valves and steampipes. The blow off connections were in the rear heads, and had been usedfor a long time for the introduction of the feed water. Reference to Fig. iwill make clear the general arrangement of the boilers, and will… … I Fig. I. Details of Boilers 301, 302, and 303. Hie report of the Hartfords inspector shows that these boilers, aside fromage were in apparent good order. There was evidence that no rivets hadbeen replaced, and that the seams had never been chipped and caulked. Nofire cracks were visible, and…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
