Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 179
r boiler shells. Thetotal tangential stress in the material of any cylinder is not evenly distributedthroughout the thickness t of the material, but gradually diminishes fromthe inner skin of the plate toward the outer skin, so that the maximum stressoccurs in the inner skin of the metal.… … Fig. 2. Fig. namely: For the sake of simplicity we might use the usual boiler shell formula,P> R but this would be at the sacrifice of accuracy, since it produces a result that is considerably less for thick walledstructures of small diameter than Lames formula, which is theoretically…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
