Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 50
Fig.4. To exhibit this action more clearly, a one-fourth size rubber model of asection of this seam was made, as seen in Fig. 5. Fig. 6 shows a profile ofthe model before tension was applied, and Fig. 7 indicates clearly the effectof tension on the seam. Particular attention is invited to the… … 38 THE LOCOMOTIVE. [April, This evidence naturally led to a desire to determine if possible, the natureand extent of the inward deflection of the vertical cover plate under workingconditions, and for this purpose a deflection gage was devised as in Fig. 8. The frame of the instrument was made from…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
