during the process. Seams,including the bottom head seam, were welded. The seam which failedwas the vertical seam of the upper of two courses, and it was adouble V butt weld. Examination of the weld metal, as illustrated in Figures 3-6, re-vealed a definitely defective weld, which, coupled with the… … Figure 2. Wreckage caused by the explosion and the subsequent col-lapse of the building.
