Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 189
Fio. 3.Combined Check and Stop Valve. 180 LOCOMOTIVE APPLIANCES. at the left of the stem, which allows the volume ofpassage to be varied, and thereby proves valuable forvery careful adjustment in the working of injectors. … Fig. 4.Mailer Turbine Boiler Check Valve. The rotary seat insures an even wear and long life,and the mode of passage of fluids insures a cleanvalve at all times. LOCOMOTIVE SLIDE VALVES. The valve is the device which admits steam to, andallows it to exhaust from the cylinder of every steamengine.…
Locomotives
