Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 363
Fig. 3.Heath Feed-Water Strainer. H-D LOCOMOTIVE STRAINER. The H-D locomotive strainer is an improved form of hose strainer giving full area, and can be used foreither the right or left hand side of the locomotive.The screen is circular in form and rigidly attached to 23 354 LOCOMOTIVE APPLIANCES.… … Fig. 4.The H-D Locomotive Strainer. THE HANCOCK LOCOMOTIVE HOSE STRAINER. The hose strainer illustrated by Fig. 5 consists ofa perforated copper plate in a metal frame which fitsinto slides in the body. The perforated copper plate
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
