Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 474
eair connection leading from a small operating valve inthe cab. B is the ordinary delivery pipe leadingto the rail, and D is a loose tube at the opening ofdelivery pipe B. Directions for Applying.—Cut the sand pipe justabove the running board, or where sanders can begotten at conveniently. To Clean… … Fig. 1.A-B-C Track Sander. THE MUDD AIR SANDER. This device is shown in detail by Figs. 1, 2 and 3,and is seen to be operated in conjunction with theoriginal slide valve sand-lever device. One-inchstandard pipe should be used for the forward deliverypipes, and one-half inch standard for the back…
Locomotives
