without shut-ting off steam. When the by-pass valve is opened theoil will flow directly from the oil reservoir through theby-pass valve to the oil pipe. They can be regulated to 9 10 LOCOMOTIVE BREAKDOWN QUESTIONS feed the same as the feed valves when necessary, but itv^ould not be a sight-feed… … 4. Positions of Eccentric Rods in Relation toLink Block.—What are the positions of the eccen-tric rods.in relation to the link block in full forward andfull backward motion? Answer.—Nearly opposite the link block in both mo-tions. 5. Front-End Appliances.—Name what adjust-ments can be made to the…
