Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 373
Fig. 296 [ 362 PRACTICAL APPLIED ELECTRICITY circuits are equal and displaced in phase from their electro-motive forces by the same angle, the three currents are then120 degrees apart and their vector sum, which is the currentin main (4), is zero. Hence, for a balance load, main (4)carries no… … 0 90* 180* 270* 360*Fig. 297
Electrical engineering
