Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 541
ON LINE 8-8 Figs. 338 and 339. Sections of Schenectady Compounds. pistons. These valves traverse endwise a cylindrical chest C1,which has ports cA c2 opening into the low-pressure inlet pipeE1, and with bearings c therein, in which the piston head G2 SCHENECTADY COMPOUND. 527 traverses; these…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
