Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 219
S X =?■ … PLATE 85.BROKEN SIDE ROD. If a side rod breaks on an eight-wheel engine theopposite rods to those which are broken should alsobe taken off. On a ten-wheel engine with the knucklejoint back of the main pin, if the back section of therod breaks, it will be necessary to take down theopposite rod. If a…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
