links of unequal length, connected at their upper extremities with the endsof the eccentric-rods, one of which is above and one below the studs on the lever of the valve-shaft, sothat the upper eccentric-rod, being in geer, gives the forward motion, and the lower gives the backwardmotion. In other… … 518 ENGINES, DETAILS OF. and by the same movement the backing eccentric is lifted into geer by a longer link connecting it to alever, not upon the reversing shaft, but upon a shaft below it. Stephenson and Hawthorn have both\ised a similar arrangement, but admitting of the eecentric-rods being both…
