^ plates. In such a design the overlap below thetop of the bed should be made sufficiently strong to resist theturning action from TF3. B and C show the application of gibsbetween the sliding head and the bed to take up side slack. In)me classes of machines gib arrangements are essential. If, … Fig. 116. however, heavy side thrusts are involved the form C is question-able unless made very heavy and strong. With the bed planedto an angle as at C and D, the latter would be considered thestronger. Sliding Head.—Since the sliding head cannot be rigidly fastenedto the bed, it must be fitted to…
