The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 111
824. … 106 THE ENGINEERS SKETCH-BOOK. 834. Centre bearing, with annular grip, for a heavy centre piece or car bogie. 835. Centre bearing, with allowance for some amount of oscillation.Coupled bearings. No. 671. Section 47.—PLATE WORK. 836. Single riveted lap joint. 837. Double riveted lap joint. 838.…
Mechanical movements
