Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 134
wmade up of two cantilevers each having a length of where w is the width of band. The spring usually contains several full-length leaves with blunt ends, the remaining leaves beinggraduated as to length and pointed as in Fig. 38. The bluntfull-length leaves constitute a cantilever of uniform… … FiG. 38. posing that there is no initial stress between the leaves causedby the band, both sets must have the same deflection. Thismeans that more than its proportion of the load will be carriedby the full-length set and consequently it will have a greaterfiber stress. This difiiculty can be…
Machine design
