efullydesigned. The smaller wheelcast in one piece is more orless subject to stresses causedby shrinkage. The sectionalwheel is generally free fromsuch stresses but is weakenedby the numerous joints. Rim j oints are of two gen-eral classes according as boltsor links are used for fastenings. Wide,… … Fig. 94. FLY WHEELS 205 As will be shown later, the former is a weak and unreliablejoint, especially when located midway between the arms. The principal stresses in fly-wheel rims are caused by centrifu-gal force. 102. Safe Speed for Wheels.—The centrifugal force developedin a rapidly revolving…
