Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 235
ame as in equation (110). If the metal be perfectly elastic, Stodolas formulas give uWV S= as the stress near the center when d approaches 0 — or more than twice the value given in (122). In view of theimperfect elasticity of the metals used the true value will prob-ably be between these two. This… … Fig. 97. D = outer diameter in inches d = inner diameter in inches 6 = breadth of ring at inner circumferencem = tangent of angle of slant CAD Then m D-d or h D-d m ROTATING DISCS 217 By cutting the ring into slices perpendicular to the axis,finding the centrifugal force for each slice and then…
Machine design
