Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 274
Ftg. 106. TOGGLE-JOINT DETAILS 243 … Fig. 107. double shear to get the minimum size allowable, but this sizewill probably be so small that it will be necessary to increase thesize of both pin and hub to add symmetry to the design. Suchpoints as this call for special investigation. Any piece of amachine may be made extra strong, if…
Machine design
