Fig. 41. Fig. 41 shows the spindle of an engine lathe completewith its two bearings. The end thrust is taken by afiber washer backed by an adjusting collar and checknut. Both bearings belong to the class shown inFig. 40. A conical journal with end adjustment is illustrated LUBRICATION. 99 in Fig,… … Fig. 42. for wear by drawing it back into its bearing with thenut. The rear journal on the other hand is cylindricaland its bearing is adjusted as are those just described.The end thrust is taken by two loose rings at the frontend of the spindle. 44. Lubrication. The bearings of machines whichrun…
