Fig. 7. 24 MACHINE DESIGN. Exercises. 1. Discuss the stresses and the arrangement of material inthe girder frame of a Corliss engine. 2. Ditto in the G frame of a band saw. Problem. Design a G frame similar to that shown in Fig. 7, for a shearpress capable of shearing a bar of mild steel 1| by 1£… … Fig. 8. ii. Thin Shells. Let Fig. 8 represent a section ofa thin shell, like a boilershell, exposed to an inter-nal pressure of p poundsper sq. inch. Then, if weconsider any diameter AB,the total upward pressureon upper half of the shellwill balance the total down-ward pressure on the lowerhalf and…
