Machine design; a manual of practical instruction in designing machinery for specific purposes, including specifications for belts, screws, pins, gears, etc., and many working hints as to operation and care of machines (1918)
Wallace, Ernest L · Chicago, American technical society · leaf 37
. 11 the arrows indicate the values and the directions of the shearing stresses on ver,small portions of the cross-section of a shaft there represented. Resisting Moment. By resisting moment at a section of ais meant the sum of the moments of the shearingcross-section about the axis of the shaft.… … Fig. 11. Cross-Sectionof Shaft shaftstresses on the MACHINE DESIGN 27 and dt inside diameter. Then it may be shown that the resistingmoment T is r-;^- (5) where c is the distance of the most remote fiber from the neutral axis,and I is the polar moment of inertia. This is not the same as thedirect…
