Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 15
Fig. 3. Rectangular Block Within a GlassBox, the Surfaces Projected to the Top, Front,and Right-Hand Side … Fig. 4. First and Preferred Method of Show-ing Top, Front, and Right-Hand Side Views ofa Rectangular Block on a Plane Surface MACHINE DRAWING r B Fig. 5. Method of Showing Five Views of aRectangular Block on a Plane Surface right of, and the view of the left-hand side is on the left of the…
Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
