Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 209
itively fixed in position by two dowels, \ inch in diam-eter. The holes in both bracket and yoke are drilled through bothpieces at the same operation. This very common method of fixingbolted parts of machinery in absolute position not only assuresfirmness, but also in case of removal, permits the… … MACHINE DRAWING 197 same level as that beneath the water cylinder. The tapped holes inthe top surface receive bolts from the cylinder foot. These boltsare often used only for shipping purposes, the cylinder foot whenthe pump is set up being allowed to slide freely on the cricket, thuspermitting…
