Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 97
Fig. 7G. Simple Diagram of a Cam 84 MACHINE DRAWING … thereto. In order to do this, the several positions of the followerin its path may be laid down on the drawing paper as shown in Fig.77. This fixes the limit through which the cammust move the follower. Now develop the camitself on a separate piece of transparent paper ortracing cloth, Fig. 78, and…
Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
