Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 84
ch distances is simple and oftena convenience. Thus it is easy to see that in the diagram thevertical lines from 1, 2, 3, and 4 cut the diagonals proportionatelyto the divisions on GH^ in this case into six equal parts. Thesedivisions can in turn be transferred to EF by horizontal linesfrom the… … Perspective representation of above.Fig. 103
Drawing · Perspective
