Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 139
Fig. 105. Belt Drive with Main Pulleys of DifferentDiameters 126 MACHINE DRAWING Smith in Transactions of the American Society of MechanicalEngineers (Vol. 10, p. 269). Here the distance between shafts anddiameters for one cone pulley is assumed, or is known from theconditions of the drive. In Fig.… … Fig. 106. Cone Pulleys for Spindle and Countershaft given cone pulleys. Draw the belt line EF. From a point G, half-way between A and- B, erect GH perpendicular to AB, and makeit equal to 3.1416 AB (for the sake of space, it is not drawn to thisscale in the cut). With H as a center, draw a circle…
