Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)

Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 273

An illustration from Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator, 1914, leaf 273
ill be noted that the castingsfor the bearings, pedestals, caps, etc., are somewhat complicated,and complete information is given in the drawings so that thepattern maker can make proper patterns and core boxes for pro-ducing these castings. A number of half-sections on the maindrawings and… … MACHINE DRAWING 259 DETAILS OF ELECTRICAL CONNECTIONSPLATE P. ASSEMBLY OF CONNECTIONS The next work which will be necessary in the drawing room isa layout of the connections between fields and between the busrings and terminal blocks at the side of the machine. Before theactual layout of these…
